ROTARY PISTON BLOWER DKG

Low operating costs through high efficiency.

The DKG rotary piston blowers are especially designed for applications in which an even, high negative pressure is needed (high-vacuum area). The devices have a very steady characteristic curve. Thus, long, widely branched pipe systems with many extraction points can be connected. They work with extremely low noise and are suitable for the extraction of dusts and shavings due to their upstream filter unit.

Applications

Multi-workstation extraction in industry

Applications needing a constant negative pressure

Ideal for these processes

High-vacuum extraction

Types of dust

Shavings

Dusts

Types of set-up

Stationary setup

Central extraction systems are able to carry out extraction on multiple machines in parallel from its location via a pipe system.

Your benefit

Constant negative pressure

Low operating noise through sound isolation and separate placement
Wear- and maintenance-free construction
Low operating costs through cleanable filters and high energy-efficiency

Downloads & data DKG series

Rotary piston blower DKG	11	15	37	75
Max. air volume m³/h	510	840	1.860	3.720
Intake diameter mm	80	100	150	200
Max. negative pressure Pa	40,000	40,000	40,000	40,000
Nominal power* kW	11.0	15.0	37.0	75.0
Motor speed 1/min	2,915	2,925	2,945	2,970
Dimensions (B/H/T) mm	1,230 x 1,306 x 1,200	1,230 x 1,306 x 1,200	1,655 x 1,820 x 1,600	2,110 x 2,330 x 1,750
Sound level dB(A)	71	72	78	85
