360° EXTRACTION TABLE
ROTATABLE EXTRACTION TABLE FOR CONNECTION TO AN EXTRACTION SYSTEM OR A FAN
The 360° extraction table is especially suitable for mechanical and thermal separation processes. The turning function of the table around its own axis allows users all-round access to their workpiece - which reduces time-consuming clamping processes. Thanks to the optimised airflow and the flexible hood over the working area, the 360° extraction table effectively protects employees from dust and fumes. The ergonomically designed and, if desired, height-adjustable construction also ensures safe and pleasant working conditions.
360°-Downdraft table - Rotatable extraction table with front extraction
Gallery 360° extraction table
- For connecting to fan or extraction system
- Work table for welding, grinding and de-burring of metals
- Can also be used for other applications
- Welding, soldering
- Sawing, cutting, separating
- Grinding, polishing
- Machining, milling
- Metal dusts
- Welding fumes
- Plastic chips
- Vapours
- Fumes
- CFK / GFK dusts
- Mineral dusts
- Concrete dust
Stationary setup
Fixed extraction systems which can be connected next to processing machines.
ATEX-COMPLIANT
For use in areas subject to risk of explosion.
- Welding table extraction / welding table extraction directly at the workplace
- Greater efficiency when processing workpieces
- Time saving due to fewer clamping stages
- Process shortened due to shorter cycle times
- Less pollution of the workplace
- Optimised work protection
- Accessible from all sides (360 degrees)
- Maximum workpiece width: 900 mm (with closed walls)
- Height adjustment: 980 to 1,180 mm
- Needs about 2,500 m³/h air volume
- Extraction nozzle in the front area
- Adjustable end stop
- Vice
- Side panel hinged
- Lighting
- Good ergonomics due to optimal, continuous height adjustment
- ATEX-compliant
- Hood
- Device support
Downloads & Data 360° extraction table
| Extraction table | 360° |
|---|---|
|
Connection diameter mm | 250 |
|
Dimensions (L/W/H) (without hood) mm | 1.000 x 1.140 x 970 |
|
Dimensions (L/W/H) (with hood) mm | 1.000 x 1.400 x 970 |
|
Weight kg | 160 |
CONTACT 360° extraction table
WE ARE HAPPY TO PROVIDE A PERSONAL CONSULTATION
We can adapt our exhaust installations to your needs. Tailor-made, modular and individual. Ask us!
